Madrid angle connector, glass-wall 90°

Product number: BO5215433

Description

Madrid angle connector 90° glass-wall, for connecting a wall with a fixed side panel. Only inexpensive glass drill holes are required.



Show all Show less

Your Advantages

  • Concealed screws
  • Only glass drilling required
  • Different surfaces available

Technical details

Angle
90°
Concealed wall fixings
Yes
Degree of gloss
Shiny
Flush
No
Glass thickness TSG
6 - 10 mm
Material
Brass
Mounting type
Glass-Wall
Package contents
1 Piece
Product series
Madrid
Rise/fall function
No
Screws on the belt concealed
Yes
Surface
Chrome-plated
Show all Show less
